Technical Parameter

Conductor: Silver Plated Nickel

Conductor Size: ≥0.25mm

Silver Coating Thickness: ≥2μm

Jacket:  260℃ PTFE

Color: Clear/Red/Green/Black/Yellow/Purple/Brown……

RoHS & REACH Compliance

Wire Characteristics:

1.）Silver coating layer is good for chip soldering.

2.）Silver and nickel material wire is good for heat conduction.

3.）PTFE can be done chemical etching, after etching process insulation jacket is good for epoxy resin bonding.
