Technical Parameter
Conductor: Silver Plated Nickel / Silver Plated Copper / Nickel Plated Copper / Pure Nickel
Conductor Size: ≥0.25mm
Silver Coating Thickness: ≥2μm SPN conductor
Silver Coating Thickness: ≥1.2μm SPC conductor
Jacket: 260℃ PTFE
Color: Clear/Red/Green/Black/Yellow/Purple/Brown……
RoHS & REACH Compliance
Wire Characteristics：
- Normal PTFE Wire：Normal PTFE wire insulation surface is very smooth. If there is a need to bond PTFE wire to epoxy powder/resin, it will cause the bonding adhesion to be very poor.
- Etched PTFE Wire：Our etched PTFE wire is very strong in this field. After the etching process, the PTFE surface becomes rough and full of one - layer small holes. This greatly improves the bonding adhesion strength between the PTFE layer and epoxy powder.
Microscopic View of Etched PTFE Insulation Layer：PTFE insulation layer surface after etching, as seen under a microscope at 5000 - times enlargement.
